Red Rooster

General:
Air chain hoist for material handling 140 and 250 kg.
These types RED ROOSTER Compact Hoist are very suitable for "Material-Handling". The pendant control is direct on the lower hook so the operator can control and position the load easy and direct. The perfect solution for horizontal movements is the combination with a push trolley.

Standard features:

  • Pendant control direct on the lower hook.
  • Optimum load control, very precise positioning.
  • One-hand control.
  • Variable speed control.
  • Soft start and stop, no shock movements.
  • Handle can be positioned for left-hand or righthand operation.
  • Endstop system.
  • 2 meter of lift. (Only for TMM-140AE)

Recommended:
We highly recommend the use of an SMC air treatment unit.
(Sold separately.)

Product Image 1
Product Image 2
Select a row from the table below, then click the add to quote button
Part Code WLL
ton
Type Lowering speed with load m/min Air consumption lowering (I/sec) Chainfalls Lifting speed with max.load (m/min) Weight at 3m HOL (kg) Lifting speed without load (m/min) Air consumption (l/sec)
16.30TMM-140AE 0.14 TMM-140AE 15 11 1 (Wire) 11 9 15 8
16.30TCR-250ME 0.25 TCR-250ME 16 13 1 (Chain) 8 11 19 11.7
