Aluminium body wire rope hoists

High quality aluminium wire rope hoist for pulling and lifting. The hoist does not have a wire drum as the wire goes through the hoist. Lifting and pulling speed is app. 3 m/min. The hoist is equipped with 20 m wire rope with a safety hook as a standard. Other wire rope lengths are also available upon request.

800 kg/1600 kg/3200 kg models equipped with a carrying handle.


Weight of 20 m wire ropes:
(rope weight + hoist weight from table = total weight)

  • 0,8 t: 7,2 kg
  • 1,6 t: 12,1 kg
  • 3,2 t: 22,8 kg
  • 5,4 t: 37,5 kg



  • Marking: According to standard, CE-marked
  • Standard: EN 13157
  • Safety factor: 5:1
