When working at height, a large lifting height, safety, and reliability are essential. KITO hoists deliver the best of all three!
KITO is the only manufacturer in the world offering electro-galvanized nickel-plated load chains. The benefits include higher corrosion resistance and reduced wear compared to traditional chains.
A dedicated solution for wind turbine applications is the ER2 WindHoist chain hoist model, available on our website.
In its standard version, it offers a working load limit of up to 800 kg. For larger capacities, KITO can provide a suitable solution. The lifting height can reach up to 150 m. An electromagnetic or disc brake available for the hoists further enhances safety.
Optional additional equipmenl
- Radio remote control
- Foam protective cover for the lower hook
- Trolleys available: standard, chain-driven, or electric motor-driven
- Special voltage options available on request
Hoist construction components
-
Top hook / upper suspension point
Enables quick and easy installation and removal of the hoist. -
Pressure die-cast aluminium housing
Extremely stable, robust design. -
Hook cover
Optional component to protect the lower hook, in a highly visible color. -
Lower load hook
Swivel bottom hook rotating 360° to prevent chain kinks and twists that can lead to hazardous situations. -
Control pendant
Ergonomic design for easier operation. -
Nickel-plated chain
Class T chain, V series (G100) compliant with EN 818-7, tensile strength 1000 N/mm² (special solution). -
Chain stopper
Working load limit (WLL)
Up to 800 kg as standard. Higher capacities available on request.
Operating voltage
Three-phase 400/690 V; other voltages available on request.
Lifting height
Up to 150 m. Greater heights available on request.
IP protection class
IP55.
Brake
Available with electromagnetic or disc brake.
Load sprocket / drive wheel
5 or 6 chain pockets (depending on model) for smoother operation.
Lifting speed
Up to 28 m/min.
Classification
FEM 1Bm, ISO M3; other classifications available on request.
Drive protection
Thermal protection of the drive system (PTC).
Motor
Fan-cooled.
Load chain
Nickel-plated or galvanized load chain, depending on customer requirements.
