MINIFOR™ hoists are used with a Maxiflex wire rope. They can be used to lift or pull objects over great distances depending on the wire rope length. They are suitable for use in numerous configurations. They are operated through a pushbutton control. Optionally, the MINIFOR™ hoist can be equipped with a wire rope reeling device or a wireless remote control.

TR110 is fitted with an overload protection system

  • Capacity 100 kg, 300 kg or 500 kg
  • Quick installation
  • Easy to use, light-weight, robust, powerful
  • Available as single phase and three phase model
  • Excellent capacity / weight ratio
  • Unlimited wire rope travel
  • Pendant control (up/down/emergency stop) 2,5 m
  • Aluminium alloy design
  • Swivelling suspension hook
  • Protection: IP55 (Control: IP65)
  • Upper and lower limit switches

Options:

  • Special sleave block kits are available for all models (max. 980 kg). They enable doubling the capacity half the working speed
  • Extension power supply and control cabel per m.
  • Radio remote control
  • Wire rope 10-100 m in 10 m. length interval. Other lengths on request
  • Do only use original Minifor steel wire rope
  • Metal storage box
  • Wire rope reeler
  • Alternatively with cable reeling device (max. 40 m), wireless remote control, set of sheave blocks
  • Marking: CE-marked, Load capacity, serial number.
  • Note: Excl. wire (to be ordered separately).
Minifor TR10
TR30 with blockkit
Minifor TR50
TR10 TR30_dwg TR10 TR30_dwg TR10/TR30 TR30S-TR50_dwg TR30S-TR50_dwg TR30S/TR50
Select a row from the table below, then click the add to quote button
Part Code WLL
ton
Type WLL sheaved
ton
Speed direct
m/min
Speed sheaved
m/min
A
mm
B
mm
C
mm
D
mm
E
mm
F
mm
G
mm
H
mm
I
mm
J
mm
K
mm
L
mm
M
mm
Weight
kg
16.28042789 0,1 TR10 0,2 15 7,5 427 20 140 631 209 112 20 20 324 356 114 15 - 20
16.28042889 0,3 TR30 0,6 5 2,5 427 20 140 631 209 112 20 20 324 356 114 15 - 20
16.28042989 0,3 TR30S 0,6 13 6,5 430 20 212 642 365 224 194 90 20 20 347 492 302 33
16.28044849 0,5 TR50 0,95 7 3,5 430 20 212 642 365 224 194 90 20 20 347 492 302 33
Wire rope ø 6,5 mm
Type Dimensions Power supply* Wire rope reeler Radio
  LxWxD mm Single phase Single phase 3 phase 20 m 27 m 40 m control
115 Volt 230 Volt 400 Volt

TR10 355x420x180

TR30 355x420x180

TR30S 495x425x225

TR50 495x425x225

TR55

TR110

* Power supply 50 and 60Hz
